LED Driver flicker-free 36W 800mA / 40W 900mA / 45W 1050mA

In Brief

• 36W 800mA / 40W 900mA / 45W 1050mA
• Anti-glare - productivity enhancing
• No flicker for photography
• Easy connection

• Constant current
• DC connector
• 50,000 hours
• 2 Years warranty

Flicker-Free

Many light panels have flickering light. This is not visible to the naked eye. You can often see this by pointing a camera at the light; you will then notice that the image flickers. You may not consciously experience this flicker, but it can affect aspects such as focus, fatigue, irritated or tired eyes, headaches, or a general irritated feeling. A flicker-free LED driver has a special chip that prevents the light from flickering (invisibly). This can enhance productivity and mood.

LED Driver 36W

This external LED driver has an output voltage of 800mA and is suitable for LED panels that have an output voltage of 700-800mA. You can also use this LED driver for other types of LED lighting.

LED Driver 40W

This external LED driver has an output voltage of 900mA and is suitable for LED panels that have an output voltage of 850-900mA. You can also use this LED driver for other types of LED lighting.

LED Driver 45W

This external LED driver has an output voltage of 1050mA and is suitable for LED panels that have an output voltage of 950-1050mA. You can also use this LED driver for other types of LED lighting.

Always check the specifications of your lamp to see if the mA rating matches between the lamp and the driver. The mA rating of the LED driver can be slightly higher than that of the lighting.

Connecting the LED Driver

This driver is easy to connect to, for example, an LED panel. Always ensure that you are working without power when connecting a driver.

This driver has 3 wires: one L and N wire, and a DC connector.

1. The L and N wires are connected directly to the mains, which you can safely and quickly do with  terminal blocks . You will need 1 for each wire, so in this case, you will need 2.
2. Finally, click the DC connector onto the LED panel.
