T5 LED Tube Fittings

These slim T5 fittings are pre-wired for single-end powered T5 LED tubes: insert the tube, connect the supply cable and you are done. There is no ballast or starter inside. With a profile of about 2.5 by 3.5 cm they fit where a T8 fitting is too large: under kitchen cabinets, above a workbench, in cupboards and display cases, above shelving or as a light line in a corridor.

In stock and ordered before 2 pm on a working day? We ship the same day, with free shipping above your country's threshold. Business customers can buy on invoice with volume pricing; for larger quantities we are happy to prepare a custom quote.

Which fitting for which tube?

120 cm T5 fitting: for a 1148 mm T5 LED tube, 18W and up to 3,600 lumens.
150 cm T5 fitting: for a 1448 mm T5 LED tube, 25W and up to 5,000 lumens.

The fitting is supplied without a tube. Choose the tube in the colour temperature and light output that suits your space.

Frequently asked questions about T5 fittings

Can I use a standard T5 fluorescent tube?

No. There is no ballast inside; the fitting is only intended for single-end powered T5 LED tubes.

How do I connect the fitting?

To 230V, with live and neutral on the terminal at the marked supply end. Fit the tube with its supply end on the same side. If you have no electrical experience, have an electrician do the connection. LED tube installation guide

Is the fitting suitable for damp areas?

No, use it in dry indoor spaces. For garages, cellars and outdoors, choose a waterproof fitting with a T8 tube.

I already have T5 fittings with a ballast: do I need a new one?

Then you do not need a new fitting. The existing fitting can be converted: the ballast is removed and the LED tube receives 230V directly at one end. How this works is explained under T5 LED tubes.

Do you supply for projects?

Yes. Volume pricing applies to larger quantities and business customers can buy on invoice. Request a quote and we will be happy to work out the numbers with you.

See all T5 LED tubes or the full range of LED tubes.
