LED Strip COB 10W/m IP20 | 5 meter

COB LED Strip 10W per meter IP20 for smooth and professional light lines

This COB LED strip delivers a fully smooth and dot free light effect thanks to 480 LEDs per meter and high quality CRI>90 color rendering. With 10W per meter, durable materials and a wide 170 degree beam angle, this strip is ideal for cove lighting, furniture, kitchens, living spaces and professional interior projects. The strip runs on safe 24V low voltage, offers a long lifespan and delivers consistent light quality without visible hotspots.

Main features

• Perfectly smooth light line without visible dots
• 10W per meter with about 90 lumens per watt
• Approx 900 lumens per meter light output
• 480 LEDs per meter for ultra consistent lighting
• CRI>90 for natural and accurate colors
• Wide 170 degree beam for soft and even illumination
• Cutting length: 50 mm for perfect precision
• Thermal conductive 3M tape for long lasting adhesion
• Dimensions: 5000 x 8 x 2.3 mm
• Lifespan up to about 50,000 hours
• 5 year warranty for long term reliability

Premium finish with COB technology and professional PCB design

The LEDs are mounted directly on a double sided PCB with electrolytic copper. This ensures excellent heat dissipation and long lasting performance. The wide 170 degree beam creates soft, shadow free light which is ideal for modern interiors and visible light lines.

The back of the strip features heat conductive 3M tape that adheres firmly to smooth surfaces and helps keep the strip cool. This ensures stable light quality for many years.

Flexible, bendable and easy to shape

The flexible FPCB allows the strip to bend effortlessly around corners, furniture or architectural details. Cutting is possible every 50 mm on the marked points.

• Straight connector
• 90 degree angle connector
• T connector
• Cross connector
• Flexible connectors for curves

Connection options:

• DC connector
• 2 pin cable

Stable light output with dual power feed

This strip is equipped with dual power leads at both ends. This allows center feeding, looping or longer installations without noticeable brightness loss. The low voltage drop ensures that the full 5 meter remains evenly illuminated.

Selecting the right 24V power supply

This strip consumes 10W per meter. A 5 meter strip therefore requires 50W. Always add at least 20 percent extra for stable performance.

• 1 to 5 meters: 24V 60W power supply
• 5 to 10 meters: 24V 100W power supply
• 10 to 15 meters: 24V 150W power supply
• 15 to 20 meters: 24V 200W power supply

Brightness consistency over longer distances

The high quality PCB and dual power feed deliver stable performance across the entire 5 meter length.
